Vivo X500 Pro Max, X500 Pro and X500: Complete Review, Specs, Camera and Battery

Vivo has expanded its flagship smartphone lineup with the new X500 series, introducing three models instead of the two devices offered in the previous generation. The lineup now consists of the vivo X500, vivo X500 Pro, and vivo X500 Pro Max.

The new series puts a major emphasis on photography and professional video recording. While all three smartphones offer capable camera systems, the Pro and Pro Max models receive more advanced imaging hardware and additional video features.

Another major highlight is battery capacity. Vivo has equipped the X500 series with large batteries, while 90W wired charging and 40W wireless charging are available across the lineup.

Vivo X500 Series Overview

The three phones target different types of users.

The vivo X500 is the standard model, offering a large display, a 7,500mAh battery and a capable triple-camera system.

The vivo X500 Pro takes a more compact approach while adding upgraded camera hardware and the Dimensity 9600 Pro chipset.

At the top of the lineup sits the vivo X500 Pro Max, which combines a large 6.85-inch display, an 8,000mAh battery, a 200MP telephoto camera and advanced professional video recording features.

Vivo X500 Pro Max

The vivo X500 Pro Max is the flagship model of the new series and offers the most advanced camera setup and largest battery in the lineup.

It features a 6.85-inch LTPO AMOLED display with a 144Hz refresh rate, a MediaTek Dimensity 9600 Pro chipset and up to 1TB of storage.

Vivo X500 Pro Max Design

The X500 Pro Max measures 163.3 x 76.8 x 8.1mm and weighs approximately 225 grams.

The phone uses a glass front, an aluminum frame and either a glass or glass-fiber reinforced plastic rear panel, depending on the version.

Vivo has also given the phone IP68 and IP69 protection, providing resistance against dust and water, including high-pressure water jets.

6.85-Inch 144Hz AMOLED Display

The X500 Pro Max features a 6.85-inch LTPO AMOLED display with a resolution of 1440 x 3168 pixels.

Key display features include:

• 144Hz refresh rate
• HDR10+
• Dolby Vision
• 1 billion colors
• Up to 2,000 nits HBM brightness
• Up to 4,400 nits peak brightness
• 507ppi pixel density
• Ultra HDR image support

The LTPO technology allows the refresh rate to dynamically adjust depending on the content, helping balance smoothness and power efficiency.

Dimensity 9600 Pro Performance

Powering the X500 Pro Max is the MediaTek Dimensity 9600 Pro, built using a 2nm manufacturing process.

The phone is available with configurations offering up to 16GB of RAM and 1TB of UFS 4.1 storage.

Available options include:

• 256GB + 12GB RAM
• 512GB + 12GB RAM
• 512GB + 16GB RAM
• 1TB + 12GB RAM
• 1TB + 16GB RAM

This hardware combination is aimed at demanding applications, gaming, multitasking and high-resolution video processing.

Vivo X500 Pro Max Camera

Photography is one of the main attractions of the X500 Pro Max.

The rear camera system consists of three cameras:

• 50MP main camera
• 200MP telephoto camera
• 50MP ultra-wide camera

The 200MP telephoto camera is particularly notable, using a large 1/1.4-inch sensor and offering 3.5x optical zoom.

50MP Main Camera

The primary camera uses a 50MP sensor with:

• f/1.6 aperture
• 24mm equivalent focal length
• 1/1.28-inch sensor
• 1.22µm pixels
• PDAF
• Optical image stabilization

The main camera also benefits from the Sony Lytia L910 LOFIC sensor technology used in the Pro and Pro Max models, designed to provide a wide dynamic range.

200MP Telephoto Camera

The 200MP telephoto camera is one of the biggest differences between the Pro Max and Pro models.

It features:

• 200MP resolution
• f/2.7 aperture
• 85mm focal length
• 1/1.4-inch sensor
• Multi-directional PDAF
• OIS
• 3.5x optical zoom

The high-resolution sensor provides plenty of detail and gives Vivo additional flexibility for zoom and cropping.

50MP Ultra-Wide Camera

The ultra-wide camera uses a 50MP sensor with a 119-degree field of view.

It has a 15mm equivalent focal length, f/2.0 aperture and autofocus.

Professional Video Recording

Vivo has placed significant emphasis on video recording with the X500 series.

The X500 Pro Max supports recording up to 8K at 30fps, while 4K recording is available at frame rates reaching 240fps depending on the mode.

The phone also supports:

• 17 EV TrueDynamic Log
• Dolby Vision HDR
• 4K 120fps 10-bit Log
• 10-bit 4:2:2 APV
• 1080p slow-motion recording
• Professional log recording

The front camera can record 4K video at up to 60fps.

These features make the Pro Max particularly focused on users who want more control over video production.

Vivo X500 Pro

The vivo X500 Pro takes a different approach from the Pro Max. Interestingly, it is the smallest phone in the new three-device lineup.

Its compact body measures 151.8 x 71.9 x 8.1mm and weighs only 192 grams.

Despite its smaller size, the phone retains many of the flagship features found on the Pro Max.

6.36-Inch LTPO AMOLED Display

The X500 Pro has a 6.36-inch LTPO AMOLED display with:

• 144Hz refresh rate
• HDR10+
• Dolby Vision
• 1 billion colors
• 2,000 nits HBM brightness
• 4,500 nits peak brightness
• 1216 x 2660 resolution
• 459ppi

Its smaller dimensions make it an interesting option for users who prefer a more compact flagship smartphone.

X500 Pro Camera System

The X500 Pro features a 50MP main camera, 64MP telephoto camera and 50MP ultra-wide camera.

The main camera uses a 50MP sensor with an f/1.6 aperture, OIS and PDAF.

The telephoto camera is a 64MP unit with an 85mm equivalent focal length and 3.5x optical zoom.

Although it has a lower megapixel count than the Pro Max's 200MP telephoto camera, Vivo has introduced a new 1/2-inch Lytia 610 sensor developed in collaboration with Sony.

The ultra-wide camera is also a 50MP sensor with a 119-degree field of view.

X500 Pro Video Features

Video recording is another major focus.

The X500 Pro supports:

• 8K video at 30fps
• 4K at up to 240fps
• 1080p at up to 240fps
• 17 EV TrueDynamic Log
• Dolby Vision HDR
• 4K 120fps 10-bit Log
• 10-bit 4:2:2 APV

The front camera can record 4K video at 30fps and 60fps.

Vivo X500

The standard vivo X500 completes the lineup.

It has a 6.59-inch AMOLED display and is powered by the Dimensity 9600M chipset.

The phone measures 157.0 x 75.0 x 8.2mm and weighs around 211 grams.

Like its more expensive siblings, it features IP68/IP69 protection.

Vivo X500 Display

The X500's 6.59-inch AMOLED panel offers:

• 144Hz refresh rate
• HDR10+
• Up to 2,000 nits HBM brightness
• Up to 4,000 nits peak brightness
• 1260 x 2750 resolution
• 459ppi
• 1 billion colors

The display provides a high refresh rate while maintaining the premium AMOLED experience expected from a flagship-oriented smartphone.

Vivo X500 Camera

The standard X500 also comes with three rear cameras:

• 50MP main
• 64MP telephoto
• 50MP ultra-wide

The primary camera uses a 50MP sensor with an f/1.7 aperture, OIS and PDAF.

The 64MP telephoto camera offers a 72mm focal length and 3x optical zoom.

The ultra-wide camera provides a 119-degree field of view.

The front-facing camera is a 50MP unit with autofocus.

Vivo X500 Series Battery and Charging

Battery capacity is another area where Vivo has made substantial improvements.

The X500 Pro Max comes with an enormous 8,000mAh battery in the Chinese version, while the global version is listed with a 7,800mAh capacity.

The X500 includes a 7,500mAh battery, while the smaller X500 Pro has a 6,510mAh cell.

All three models support:

• 90W wired charging
• 40W wireless charging
• Reverse charging features

This means fast charging isn't limited to the most expensive model. Vivo has brought the same core charging capabilities across the entire X500 family.

OriginOS 7 and Android 17

The X500 series launches with OriginOS 7 based on Android 17.

Vivo says the latest generation of its software places greater emphasis on system fluidity and resource management.

The phones are also listed with support for up to five major Android/OS updates, providing a longer software support cycle.

Connectivity and Other Features

The X500 series offers a wide range of modern connectivity options.

Depending on the model and market, features include:

• 5G
• eSIM
• Wi-Fi 7
• Bluetooth 5.4/6.0
• NFC
• Infrared transmitter
• aptX HD
• LHDC 5
• Stereo speakers
• Ultrasonic in-display fingerprint scanner

The Chinese 1TB/12GB version of the X500 Pro Max additionally supports satellite connectivity.

Vivo X500 Series Specifications Comparison

Vivo X500 Series: What Makes It Different?

The biggest change this year is the addition of the X500 Pro Max. Instead of offering only a standard and Pro model, Vivo now has three flagship devices.

The Pro Max focuses on maximum camera capability, battery capacity and video recording. The Pro is aimed at users who want flagship features in a smaller body, while the standard X500 offers many high-end specifications at a lower position within the lineup.

The camera system is clearly one of Vivo's main priorities. The 200MP telephoto on the Pro Max, new Lytia sensors and professional video modes demonstrate how much emphasis Vivo is putting on mobile imaging.

Final Verdict

The vivo X500 series represents a broad expansion of Vivo's flagship smartphone strategy.

The X500 Pro Max stands out with its 200MP telephoto camera, 8,000mAh battery, large 144Hz LTPO AMOLED display and advanced professional video capabilities.

The X500 Pro offers a more compact alternative while retaining the Dimensity 9600 Pro processor and many of the same camera and video technologies.

Meanwhile, the vivo X500 combines a 7,500mAh battery, 144Hz AMOLED display, triple-camera setup and 90W charging in the standard model.

With large batteries, fast wired and wireless charging, high-resolution cameras and OriginOS 7, the X500 family is clearly designed around camera performance, video recording, battery life and flagship-level hardware.
